Description
Application:
Heavy duty sliding door: 300-500KG doors for Cool Room, Ware house,Work Shop etc
Advantage of BLDC motor system for sliding door:
Heavy Duty Sliding door: BLDC Gear Motor, compare to synchronous motor system, can achieve higher torque, lower cost.
Drive type | Input Voltage | Motor voltage | Motor model | Motor Power(W) | RPM | Max Current | Rated Torque | Max Torque(Nm) | Weight | Application on door weight | Noise | |
Direct drive | BLDC Motor system for Sliding door | 220V | 24V | TLD50 | 50 | 0-250 | 5 | 1.3 | 4 | 150Kg | 47 | |
i=5.3 Gear box | 40Nm Motor | 220V | 36V | TGD100 | 100 | 0-100 | 10 | 13.0 | 40 | 3.5 | 300Kg | 60 |
i=6 Gear box | 80Nm Motor | 220V | 36V | TGD250 | 250 | 0-120 | 20 | 20.0 | 80 | 500Kg | 60 |
